Developer Environment

Setting Up a Windows 11 Local Development Database Environment with MySQL, MongoDB, and Redis

📅 May 13, 2026 ✎ GetModNest Editor Tested on: Windows 11, MySQL 8.0, WSL Ubuntu Level: Beginner

Overview

This article documents a Windows 11 local development database setup involving MySQL, MongoDB, and Redis.

The goal was to prepare the database environment required by a development project and verify that all databases could be started and connected from the IDE.

The setup included confirming MySQL and MongoDB Windows services, running Redis through WSL Ubuntu, starting all services, testing connectivity, adjusting Redis development configuration, and verifying connections from IntelliJ IDEA.

Environment

  • OS: Windows 11
  • IDE: IntelliJ IDEA
  • MySQL version: MySQL 8.0.44
  • MongoDB version: MongoDB 8.0.15
  • Redis version: Redis 6.0.16
  • Redis runtime: WSL Ubuntu 22.04.5 LTS
  • MySQL port: 3306
  • MongoDB port: 27017
  • Redis port: 6379

Goal

The goal was to ensure that the application development environment could access all required databases locally.

The expected setup was:

  • MySQL runs as a Windows service and starts automatically
  • MongoDB runs as a Windows service and starts automatically
  • Redis runs inside WSL Ubuntu and can be started manually
  • IDEA can connect to the required project databases

Step 1: Confirm Database Service Installation

MySQL

MySQL 8.0 was already installed as a Windows service and configured to start automatically.

MySQL service exists and starts with Windows

MongoDB

MongoDB was also installed as a Windows service and configured to start automatically.

MongoDB service exists and starts with Windows

Redis

Redis was not installed as a native Windows service. Instead, it was running through WSL Ubuntu 22.04.5 LTS.

Start Redis manually inside WSL Ubuntu

Step 2: Start All Required Services

The startup order was:

  1. start Windows
  2. MySQL and MongoDB start automatically
  3. open Ubuntu in WSL
  4. start Redis manually
  5. start the development project or connect from IDEA

This ensures that all backend dependencies are available before the application starts.

Step 3: Verify MySQL Connectivity

MySQL was tested with version MySQL 8.0.44 and default port 3306.

Typical connection information:

Host: localhost
Port: 3306
User: root or application user

If MySQL cannot be connected from IDEA, check whether the service is running, port 3306 is listening, the username and password are correct, the target database exists, and the JDBC driver is downloaded.

Step 4: Verify MongoDB Connectivity

MongoDB was tested with version MongoDB 8.0.15.

Typical local connection information:

Host: localhost
Port: 27017

If MongoDB cannot be connected, check whether the MongoDB service is running, port 27017 is listening, authentication is enabled, and the database/user settings are correct.

Step 5: Configure Redis in WSL Ubuntu

Redis was running inside WSL Ubuntu 22.04.5 LTS.

Important Redis development configuration items:

bind 0.0.0.0
protected-mode no

Explanation:

  • bind 0.0.0.0 allows Redis to listen on all network interfaces
  • protected-mode no disables Redis protected mode

This is convenient for local development, but it is not recommended for production.

Step 6: Start Redis in WSL

Inside WSL Ubuntu, start Redis according to the installation method:

redis-server

or:

sudo service redis-server start

Then verify Redis is running:

redis-cli ping

Expected result:

PONG

Step 7: Test Redis Port Access

Redis default port is 6379.

From Windows or IDEA, the host may be localhost or the WSL IP address, depending on networking behavior.

redis-cli -h localhost -p 6379 ping

Expected result:

PONG

If Windows cannot connect to Redis inside WSL, check whether Redis is listening on 0.0.0.0, WSL localhost forwarding works, Windows Firewall allows access, and Redis is actually running.

Step 8: Test Connections in IntelliJ IDEA

In IDEA, open the Database tool window:

View -> Tool Windows -> Database

Then add data sources for MySQL, MongoDB, and Redis if plugin or datasource support is available.

For each database:

  1. create a data source
  2. enter host, port, database, username, and password
  3. download the driver if IDEA prompts for it
  4. click Test Connection

Step 9: Confirm Application Database Requirements

For MySQL, verify:

SHOW DATABASES;

For MongoDB, verify:

show dbs

For Redis, verify:

redis-cli ping

If the project expects an initial schema or seed data, import it before running the application.

Security Notes for Local Development

The Redis settings:

bind 0.0.0.0
protected-mode no

are convenient for local development but risky in production.

For production or shared networks, Redis should use a restricted bind address, password authentication, firewall rules, and no public exposure.

Likewise, MySQL and MongoDB should not be opened to untrusted networks without proper accounts, passwords, and firewall restrictions.

Troubleshooting Checklist

MySQL

Get-Service *mysql*
netstat -ano | findstr 3306
mysql -u root -p -h localhost -P 3306

MongoDB

Get-Service *mongo*
netstat -ano | findstr 27017
mongosh

Redis

redis-cli ping
ss -lntp | grep 6379

Common Issues

1. MySQL Works but IDEA Cannot Connect

Possible causes include wrong password, wrong port, missing JDBC driver, missing database, or insufficient user permission.

2. MongoDB Service Is Running but Connection Fails

Possible causes include authentication requirements, wrong host or port, localhost-only binding, firewall rules, or driver issues.

3. Redis Works in WSL but Not from Windows

Possible causes include Redis bound only to 127.0.0.1, WSL localhost forwarding issues, Windows Firewall blocking access, or Redis not running.

4. Application Starts Before Databases Are Ready

Start the databases first, then start the application.

  1. MySQL
  2. MongoDB
  3. Redis
  4. application backend
  5. frontend or API testing tools

Final Conclusion

The Windows 11 development environment was prepared by combining native Windows database services and WSL-based Redis.

The final environment consisted of MySQL 8.0.44 as a Windows service, MongoDB 8.0.15 as a Windows service, Redis 6.0.16 running in WSL Ubuntu 22.04.5 LTS, and IDEA database connections tested successfully.

The main lesson is that a local development database environment should be verified in layers: service status, port listening, command-line client connection, IDE connection, and application connection.

Testing each layer separately makes database environment issues much easier to locate.
