Training RF-DETR on a Custom COCO Dataset with PyTorch and CUDA

📅 May 16, 2026 ✎ GetModNest Editor Tested on: PyTorch Level: Intermediate

Overview

This article records a practical RF-DETR object detection training workflow on Windows with a custom COCO-format dataset.

COCO dataset -> RF-DETR -> PyTorch CUDA -> training -> evaluation

Environment

OS: Windows
Python: Anaconda
Model: RF-DETR Medium
Dataset: Custom COCO
GPU: RTX 4090 24GB
CUDA: 12.1
PyTorch: torch 2.9.0 + cu121

Dataset

train: 6673 images, about 2.52GB
valid: 1102 images, about 422MB
test: 1102 images, about 422MB
path: D:/zzH/DVD-COCO

COCO Label Check

A common error is invalid category IDs.

CUDA error: device-side assert triggered
index out of bounds failed
category_id should start from 1
category_id should not exceed class count
bounding boxes should be valid

Install RF-DETR

git clone https://github.com/roboflow/rf-detr.git
cd rf-detr
pip install -e .

Training Script

from rfdetr import RFDETRMedium

model = RFDETRMedium()
model.train(
    dataset_dir="D:/zzH/DVD-COCO",
    epochs=100,
    batch_size=16,
    grad_accum_steps=2,
    lr=0.0001,
    output_dir="D:/zzH/rfdetr/output",
)

Windows Fix

if __name__ == "__main__":
    import multiprocessing
    multiprocessing.freeze_support()
    main()

Metrics

class_error
loss_ce
AP@50
AP@50:95
AR@100

Troubleshooting

  • CUDA assert: check category_id and annotations.
  • Loss not decreasing: check labels, boxes, learning rate, and dataset quality.
  • GPU memory issue: reduce batch size or increase grad_accum_steps.

Final Conclusion

RF-DETR can be trained on custom COCO data on Windows, but label correctness is critical. Start with a short smoke test, then tune batch size, learning rate, and epochs.
